IMX230 21MP MIPI Camera Module High-Resolution Exmor RS Sensor HDR for facial recognition and drone

IMX230 21MP MIPI Camera Module High-Resolution Exmor RS Sensor HDR for facial recognition and drone

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	Sinoseen
Certification:	RoHS
Model Number:	SNS202187-V1.0

Payment & Shipping Terms:

Minimum Order Quantity:	3
Price:	10-100usd or negotiable
Packaging Details:	Tray+Anti-static bag in carton box
Delivery Time:	2-3weeks
Payment Terms:	T/T
Supply Ability:	500000 pieces/month

Inquiry

Parameter
Related products
Inquiry

Detail Information

Type:	MIPI Camera Module	Sensor:	IMX230
Resolution:	5344 × 4016	Dimensions:	(customizable)
Lens FOV:	78°(optional)	Focus Type:	Fixed Focus
Interface:	MIPI	Feature:	high-resolution、HDR
High Light:	MIPI 21MP Camera Module high-resolution Camera Module IMX230 module camera MIPI

Product Description

The IMX230 21MP camera module (SNS202187-V1.0) delivers high-speed, high-quality imaging for mobile and embedded devices. Its 1.12 µm pixels capture sharp details with low noise, while the Exmor RS™ back-illuminated design boosts sensitivity in low light.

With single-frame HDR, advanced noise reduction, and pixel binning, this module provides excellent image quality for facial recognition, drones, toy cameras, dashcams, and skin analysis devices. The optional 78° wide-angle lens covers broader scenes, and integration is seamless via MIPI CSI-2, compatible with Qualcomm, MTK, RK, HiSilicon, and Allwinner platforms.

Key Features

21MP back-illuminated stacked CMOS sensor with Exmor RS™ technology
Full resolution 5344×4016 @24fps, 4K2K at 30fps, 1080p at 60fps
Single-frame HDR support for vivid imaging
Built-in PDAF for precise focus
Optional 78° FOV, compact MIPI module

Parameter	Specification
Sensor Model	IMX230
Resolution	21MP (5344 × 4016 @ 24fps)
Pixel Array	5344 × 4016
Pixel Size	1.12 µm × 1.12 µm
Optical Size	1/2.3"
Sensor Type	Back-illuminated, stacked CMOS (Exmor RS™)
PDAF	Phase Detection Auto Focus
HDR	Single frame HDR with equivalent full pixels
Max Frame Rate	Full resolution 24fps, 4K2K 30fps, 1080p 60fps
Output Format	RAW10/8, COMP8/6
Output Interface	CSI-2 serial data (2/4 lane, 1.5 Gbps/lane, D-PHY v1.1)
Features	Pixel binning, HN sub-sampling, Chroma & RAW noise reduction, flip/mirror, dual sensor sync, dynamic defect pixel correction, built-in temp sensor, OTP ROM 9Kbit
Power Supply	Analog 2.5V, Digital 1.1V, I/O 1.8V
Focus Type	Fixed Focus
Field of View	78° (optional)
Module Size	22 × 10.8 mm
IR Filter	650nm
Applications	Facial recognition, skin analysis, drone cameras, toy cameras, pattern detection, dashcams
Supported Platforms	Qualcomm, Allwinner, MTK, Spreadtrum, HiSilicon, MStar
