1920*1080 Camera Module USB2.0 30FPS UVC
Product Details:
|
Place of Origin: |
Shenzhen,China |
|
Brand Name: |
Sinoseen |
|
Certification: |
RoHS |
|
Model Number: |
SNS-GM1232-V1.0 |
Payment & Shipping Terms:
|
Minimum Order Quantity: |
3 |
|
Price: |
negotiable |
|
Packaging Details: |
Tray+Anti-static bag in carton box |
|
Delivery Time: |
2-3weeks |
|
Payment Terms: |
T/T |
|
Supply Ability: |
500000 pieces/month |
- Parameter
- Related products
- Inquiry
Professional 1920*1080 Camera Module: USB2.0 UVC Full HD Solution
In embedded vision systems requiring reliable full HD performance with zero driver installation, the 1920*1080 camera module has become the industry standard. Built around a high-performance 1/3" CMOS sensor with 2.7μm large pixels, this module delivers true 1920×1080 resolution at 30 fps in both MJPG and YUY2 formats via a standard USB 2.0 High-Speed (480 Mbps) interface. With the global USB camera module market projected to exceed USD 8.5 billion by 2030 at a CAGR of 11.8%[1], our usb 1920*1080 camera module offers B2B integrators a mature, plug-and-play platform for rapid deployment.
Featuring UVC 1.1 compliance and a default M12 3.0mm F2.2 lens (92° DFOV), the full hd 1920*1080 camera module supports Windows, Linux, Android, and macOS without custom drivers. Enterprises sourcing wholesale 1920*1080 camera module volumes benefit from stable supply, while customized 1920*1080 camera module services enable lens, cable length, and housing modifications for specific uvc 1920*1080 camera module applications.
Key Product Advantages
- True Full HD Performance: Native 1920×1080 @ 30 fps with 74 dB dynamic range and 37 dB SNR in full hd 1920*1080 camera module.
- Standard UVC Compliance: Driver-free operation across major OS in uvc 1920*1080 camera module environments.
- USB 2.0 High-Speed Interface: Up to 260 Mbps effective bandwidth with MJPG compression for smooth streaming.
- Large Pixel Architecture: 2.7μm pixels deliver excellent low-light sensitivity and reduced noise.
- Flexible Optical Options: Standard M12 lens mount supports fixed-focus, varifocal, or no-distortion lenses in customized 1920*1080 camera module designs.
Product Specifications
| Parameter | Specification |
|---|---|
| Sensor | 1/3" CMOS Digital Sensor |
| Effective Resolution | 1920 × 1080 (2MP) |
| Pixel Size | 2.7 μm × 2.7 μm |
| Output Formats | MJPG / YUY2 (YUV422) |
| Max Frame Rate | 1920×1080 @ 30 fps (MJPG) |
| Dynamic Range | 74 dB |
| SNR (max) | 37 dB |
| Interface | USB 2.0 High-Speed (480 Mbps) |
| Protocol | UVC 1.1 / UAC compliant |
| Lens Mount | M12 × P0.5 |
| Default Lens | 3.0 mm F2.2, DFOV 92° |
| Operating Temperature | –30°C to +60°C |
| Power Supply | 5V via USB (no external power) |
| Cable Length | 1.5 m standard (customizable) |
Product Application Areas
- Video Conferencing Systems – crystal-clear 1080p30 with uvc 1920*1080 camera module.
- Industrial Inspection & AOI – reliable USB connectivity in production lines.
- ATM & Kiosk Integration – compact size with usb 1920*1080 camera module.
- Education Document Cameras – high-definition overhead capture.
- Access Control & Gate Systems – robust performance in wholesale 1920*1080 camera module deployments.
About Sinoseen
Sinoseen, a leading China camera module manufacturer with over ten years of expertise, provides one-stop visual solutions to global B2B customers. We specialize in wholesale 1920*1080 camera module supply and customized 1920*1080 camera module development supporting USB, MIPI, and DVP interfaces through comprehensive OEM/ODM services. Our professional technical and service teams ensure seamless integration from prototype to volume production. Contact us to accelerate your project with our proven 1920*1080 camera module platform.
Customization Process
- Requirement Submission – Define lens, cable length, and housing for your customized 1920*1080 camera module.
- Optical & Mechanical Design – Select FOV, distortion level, and connector type.
- Rapid Prototyping – Functional samples delivered in 7–14 days.
- Validation Testing – Full environmental and compatibility verification.
- Mass Production – Smooth ramp-up with strict QC.
Total Cost of Ownership (TCO) Comparison
| Aspect | Sinoseen 1920*1080 USB Module | IP/Network Camera Alternatives |
|---|---|---|
| Driver Development | None (UVC standard) | Required |
| Integration Time | 1–2 weeks | 4–12 weeks |
| Power & Cabling | Single USB cable | PoE + separate power |
| Overall TCO Impact | 20–35% lower over lifecycle | Higher system complexity |
Compliance Package & Supply Chain Security
All modules are RoHS, REACH, CE, and FCC certified. Our supply chain operates under ISO 9001 and IATF 16949 standards with diversified sourcing and 12-month buffer inventory to ensure continuity.
Mass Production Risk Matrix & After-Sales KPIs
| Risk | Probability | Mitigation |
|---|---|---|
| Sensor Supply | Low | Multiple qualified sources + buffer stock |
| Yield Fluctuation | Medium | Automated testing → 98%+ yield |
| Delivery Delay | Low | Air: 5–10 days to US/EU · Sea: 20–30 days |
After-sales KPIs: 95% first-contact resolution within 24 h · 99% spare parts on-time · >99.5% first-year field reliability.
Common Buyer FAQs
Q: Is the usb 1920*1080 camera module truly driver-free on Linux and Android?
A: Yes – standard UVC protocol ensures plug-and-play on kernel 2.6.26+ and Android 4.0+ with UVC support.
Q: Can we order a customized 1920*1080 camera module with 5-meter cable and metal housing?
A: Standard lead time for custom cable/housing versions is 2–3 weeks.
Q: Does the full hd 1920*1080 camera module support external trigger or strobe?
A: GPIO trigger versions are available upon request.
Q: What is the minimum order quantity for wholesale 1920*1080 camera module?
A: Flexible MOQ starting from 100 pcs.
Q: Can the lens be changed to narrow FOV (e.g., 30°)?
A: Yes – wide range of M12 lenses from 2.1mm to 25mm available.
Industry Challenges & Solutions
-
Challenge: Driver compatibility across OS versions
Solution: Standard UVC compliance in uvc 1920*1080 camera module. -
Challenge: Long-distance USB transmission
Solution: Active extension cable options up to 20 m. -
Challenge: Harsh industrial environments
Solution: –30°C to +60°C rating with optional IP67 housing.
Footnotes
- Global USB camera module market forecast 2024–2030: MarketsandMarkets & Technavio reports.
